Motor Starter Logic using Siemens PLC Tia Portal

Learn how to write a PLC program for motor control using TIA Portal software. Understand the requirements for a motor starter logic.

Last updated: September 19, 2024 10:34 am
Viral Nagda
PLC Tutorials
No Comments
Share
7 Min Read
SHARE

The motor is an output that is used in almost all industrial applications. Without a motor, there is literally no process that can work, because some force is required to move a process. Because motors are heavy-duty electrical outputs, they also require special care in electrical wiring for a safe and long-life operation.

Contents
Motor Starter LogicSiemens PLC Tia Portal

When a PLC program is designed for operating the motor, some basic programming concepts are usually ignored by the programmer in a hurry. Such irregular design can hamper the performance of the system.

So, it is necessary to understand some general rules when you are programming a motor in PLC. In this post, we will see how to write a general PLC program for motor control using TIA Portal software.

Motor Starter Logic

Let us first understand the requirements for a motor starter logic:

  1. There must be critical interlocks for a motor present, like a control key, emergency stop, local-remote feedback, MCCB on feedback, and other types of safety signals. If any of these signals fails, then the motor will not run in any mode, be it auto or manual.
  2. To operate the motor from PLC in any mode, the starter switch must be selected in remote mode, and not local mode.
  3. The motor will run in manual mode from PLC when manual mode is selected. The push buttons for start and stop must be momentary in nature.
  4. The motor will run in auto mode from the PLC when auto mode is selected.
  5. There must be an on-delay timer for giving run commands to the motor.
  6. Generally, two alarms are checked once the motor is running – run feedback and trip. If any of these alarms occur, then too the motor will not run in any mode. The operator will first check and then reset these alarms.
  7. There should be a running hour display for the motor.
  8. There should be a status indication of the motor (running, stopped, or tripped).

Siemens PLC Tia Portal

Now, let us how to write the logic accordingly rung by rung in TIA Portal:

In this first image, we create a logic for all the critical signals and alarms considered a healthy condition for the motor. For that, we have taken all the elements in series, so that whichever input fails, the whole healthiness will be cut off.

Siemens PLC motor starter logic

In the second image, we will operate the motor in manual mode. The motor will stop running in manual mode if the stop button is pressed, or auto mode is selected, or the motor becomes unhealthy to run.

Motor starter programming in TIA Portal

In the third image, we will operate the motor in auto mode. The motor will stop running in auto mode if the run command from auto logic becomes off, or manual mode is selected, or the motor becomes unhealthy to run.

Siemens PLC motor control logic

In the fourth image, we will give an on-delay timer for the motor to run in either manual run command or auto run command.

The on-delay timer will be settable, and not pre-fixed. This gives flexibility to commissioning engineers according to the site’s prevailing conditions and process parameters.

Programming motor starter in Siemens PLC

In the fifth image, we will check the run feedback of the motor for 5 seconds. If the PLC output is on and still the run feedback input is not received within this time, then an alarm will be generated and it will cut-off the motor run command; as taken in the first rung earlier. We will set this alarm bit so that it remains latched until operator intervention.

Siemens PLC motor starter tutorial

In the sixth image, we will check the trip feedback of the motor for 5 seconds.

If the PLC output is on and the trip feedback input is received within this time, then an alarm will be generated and it will cut-off the motor run command; as taken in the first rung earlier. We will set this alarm bit so that it remains latched until operator intervention.

PLC motor starter logic with TIA Portal

In the seventh image, we will reset these two alarms by pressing the reset button.

Motor starter ladder logic in TIA

In PLC programming, a common error most forget to write is resetting the buttons. Now, we are not starting the motor in manual mode unless its conditions are met.

But what happens if then too someone presses the start button? The output will not turn on, but once the condition becomes healthy, the motor can start immediately.

This is because the start button can remain on if someone forgets to turn it off. So, to prevent this, we reset the manual push button if all the conditions are not met.

PID control for motor starter in Siemens TIA Portal

In the ninth image, we will write the PLC logic for showing the total running hours. This step is important for maintenance purposes. When the PLC output of the motor is on and the run feedback input is also on, then only the counter will start counting.

First, we increment the counter in seconds, then the seconds counter done bit will increment the minutes counter, and then the minutes counter done bit will increment the hours counter.

Also, we reset the seconds counter when the minute counter is incremented or the reset button is pressed; we reset the minutes counter when the hour counter is incremented or the reset button is pressed and we reset the hours counter when the reset button is pressed.

Siemens S7-1200 motor starter configuration

Lastly, we move the integer values in a word, depicting motor status. This is useful for graphical indication or changing the motor color in HMI / SCADA.

Safety interlock for motor starters in Siemens PLC

All this logic ensures a very safe and reliable operation of a motor through the PLC program. In this way, we saw a PLC program for motor control using the TIA Portal.
