This article shows the different types of Siemens PLC Comparator Logics and their ladder diagrams.

## Siemens PLC Comparator Logic

**Problem Description**

Implement equal, not equal, greater or equal, less or equal, greater than, check validity, and check invalidity comparators in Siemens S7-1200 PLC using ladder diagram language.

## Problem Diagram

## Problem Solution

Comparators are used for comparing two values. Say, If we want to compare two physical quantities (temperature, pressure etc.).

We can use the equal instruction to determine, if a first comparison value is equal to a second comparison value or not.

We can use the not equal instruction to determine, if a first comparison value is not equal to a second comparison value or not.

We can use the greater or equal instruction to determine, if a first comparison value is greater than or equal to a second comparison value or not. Both values to be compared must be of the same data type.

We can use the less or equal instruction to determine, if a first comparison value is less than or equal to a second comparison value or not. Both values to be compared must be of the same data type.

We can use the greater than instruction to determine, if a first comparison value is greater than a second comparison value or not. Both values to be compared must be of the same data type.

We can use the less than instruction to determine, if a first comparison value is less than a second comparison value or not. Both values to be compared must be of the same data type.

## List of Inputs and Outputs

#### Output List

- Result 1 = Q0.0
- Result 2 = Q0.1
- Result 3 = Q0.2
- Result 4 = Q0.3
- Result 5 = Q0.4
- Result 6 = Q0.5

#### Memory

- MW0 :- Comparator 1
- MW2 :- Comparator 2
- MW4 :- Comparator 3
- MW6 :- Comparator 4
- MW8 :- Comparator 5
- MW10 :- Comparator 6

## Ladder diagram for comparators used in S7-1200 PLC

## Program Description

In this program, we have used Siemens S7-1200 PLC and TIA Portal Software for programming.

**Network 1:**

If value in MW0 is equal to 2, result 1 (Q0.0) will be ON.

**Network 2:**

If value in MW2 is not equal to 2, result 1 (Q0.1) will be ON.

**Network 3:**

If value in MW4 is greater or equal than 2, result 3 will be ON.

**Network 4:**

If value in MW6 is less or equal than 2, result 4 will be ON

**Network 5:**

If value in MW8 is greater than 2, result 5 will be ON.

**Network 6:**

If value in MW10 is less than 2, result 6 will be ON

## Test Cases
