Safety Instrumented System Module Failure

Last updated: May 21, 2019 2:40 pm
Editorial Staff
Instrumentation Design Safety Instrumented System (SIS)
3 Comments
Share
3 Min Read
SHARE

The international standard IEC/EN 61508 has been widely accepted as the basis for the specification, design and operation of safety instrumented systems (SIS).

Contents
Safety Instrumented System Module FailureArticles You May Like :SIS Engineer QuestionsAlarm and Trip SystemsProcess Control SystemInstrumentation ControlFunctional Safety Questions

As the basic standard, IEC/EN 61508 uses a formulation based on risk assessment: An assessment of the risk is undertaken and on the basis of this the necessary Safety Integrity Level (SIL) is determined for components and systems with safety functions.

SIL-evaluated components and systems are intended to reduce the risk associated with a device to a justifiable level or “tolerable risk”.

Safety Instrumented System Module Failure

To categorise the safety integrity of a safety function the probability of failure is considered – in effect the inverse of the SIL definition, looking at failure to perform rather than success.

It is easier to identify and quantify possible conditions and causes leading to failure of a safety function than it is to guarantee the desired action of a safety function when called upon.

Two classes of SIL are identified, depending on the service provided by the safety function.

  • For safety functions that are activated when required (on demand mode) the probability of failure to perform correctly is given, whilst
  • for safety functions that are in place continuously the probability of a dangerous failure is expressed in terms of a given period of time (per hour)(continuous mode).

In summary, IEC/EN 61508 requires that when safety functions are to be performed as specified in terms of a safety integrity level.

The probabilities of failure are also considered in safety integrity levels, as shown

Safety Instrumented System Failure

The PFD value (Probability of Failure on Demand) is the probability of failure of a unit as a component part of a complete safety system in the low demand mode.

The PFD value for the complete safety related function is derived from the values of individual components. Sensor and actuator are fitted in the field, leading to exposed and physical stress factors (process medium, pressure, temperature, vibration, etc.).

Safety Instrumented System Modules

The risk of failure associated with these components is thus relatively high. 25 % of the entire PFD should be therefore reserved for the sensor, 40 % for the actuator.

15 % remains for the fail-safe control, and 10 % for each of the interface modules (interface modules and the control system have no contact with the process medium and are located in protected switch rooms).

Articles You May Like :

SIS Engineer Questions

Alarm and Trip Systems

Process Control System

Instrumentation Control

Functional Safety Questions

Don't Miss Our Updates
Be the first to get exclusive content straight to your email.
We promise not to spam you. You can unsubscribe at any time.
Invalid email address
You've successfully subscribed !
Thermowell Installation near Critical Equipment
Floating Vs. Grounded Voltage
Safety Instrumented System Engineer Interview Questions
Automation System Process Functionalities
Instrument Air Quality
Share This Article
Facebook Whatsapp Whatsapp LinkedIn Copy Link
Share
3 Comments
  • Jokor says:
    December 8, 2016 at 6:17 am

    Please give us analysis on the below two questions
    What is the significant use of SIS supporting tools in the SIS design stage?
    What are the already available SIS supporting tools and what is their main functionality?

    Reply
    • S Bharadwaj Reddy says:
      December 9, 2016 at 8:16 am

      You might check out http://www.sissuite.com.

      Reply
  • Florent Brissaud says:
    December 9, 2016 at 3:29 am

    Hi!
    There is a confusion in your following text: “for safety function that are in place continuously the probability of a dangerous failure is expressed in terms of a given period of time (per hour)”.

    A probability is never expressed per time unit. A probability is unitless.
    In a continous mode, the used criteria (PFH) is a frequency of failure and not a probability. By the way, the wrong term “probability of failure per hour” does not appear anymore in the second edition of the IEC 61508, because it was inappropriate.
    Regards

    Reply
