Product Sticker Machine with Weighing PLC Program

Learn how to program a Product Sticker Machine with weighing function using PLC. Perfect for students and novice PLC programmers.

Last updated: September 24, 2024 5:12 am
Editorial Staff
PLC Tutorials
No Comments
Share
5 Min Read
SHARE

This article discusses Product Weighing and Sticker machine Programs in industrial packing machines.

Contents
Product Sticker MachineIO DetailsPLC Program

Product Sticker Machine

The PLC system has 2 buttons, the START_SYSTEM (0.00) button is used to Turn On the system, and the STOP_SYSTEM (0.01) button is used to Turn Off the system. This system also uses the SENS_PRODUCT (0.02) sensor to detect products and the Limit Switch LS_PISTON_STAMP (0.03) for the Piston Stamp Interlock.

When the START_SYSTEM (0.00) button is pressed, the CONVEYOR (100.00) Output will be ON.

When the sensor SENS_PRODUCT (0.02) detects a product, the CONVEYOR (100.00) Output will be OFF for 5 seconds to weigh the product. Product weighing data will be stored in memory word WEIGHING_INDICATOR (D0).

If the product weight is equal to 15 kg (#15), then the PISTON_STAMP (100.01) Output will be ON to give a sticker to the Product. The PISTON_STAMP (100.01) Output will be OFF when the Limit Switch LS_PISTON_STAMP (0.03) is in the HIGH state.

If in 2 seconds the weight of the product is not equal to 15kg (#15), then the ALARM Output (100.02) will be ON.

Each product given a sticker will be recorded in the memory word COUNTER_PRODUCT (D100). The value in the memory word COUNTER_PRODUCT (D100) will be reset to zero “0” when the STOP_SYSTEM (0.01) button is Pressed.

Product Sticker Machine with Weighing PLC Program

IO Details

CommentInput (I)Output(Q)Memory WordMemory BitsTimer
START_SYSTEM0.00
STOP_SYSTEM0.01
SENS_PRODUCT0.02
LS_PISTON_STAMP0.03
CONVEYOR 100.00
PISTON_STAMP 100.01
ALARM 100.02
TIMER_1    T0000
TIMER_2    T0001
SYSTEM_ON   W0.00
CUTOFF   W0.01
WEIGHING_INDICATOR  D0
COUNTER_PRODUCT  D100

PLC Program

RUNG 0 (START_SYSTEM)

In this Rung, when the START_SYSTEM (0.00) button is Pressed, the memory bit SYSTEM_ON (W0.00) changes to the HIGH state. The memory bit SYSTEM_ON (W0.00) remains in the HIGH state even though the START_SYSTEM (0.00) button has been Released because it uses Latching.

The memory bit SYSTEM_ON (W0.00) will change to LOW state if the STOP_SYSTEM (0.01) button is Pressed.

Sticker machine with weighing PLC logic

RUNG 1 (CONVEYOR)

When the NO contact of memory bit SYSTEM_ON (W0.00) is in the HIGH state, the CONVEYOR (100.00) Output will be ON.

The CONVEYOR (100.00) Output will be OFF if the NO contact of memory bit SYSTEM_ON (W0.00) is in the LOW state or the NC contact of memory bit CUTOFF (W0.01) is in the HIGH state.

RUNG 2 (CUTOFF CONVEYOR)

In this Rung, when the NO contact of memory bit SYSTEM_ON (W0.00) and Sensor SENS_PRODUCT (0.02) in the HIGH state, then the memory bit CUTOFF (W0.01) will change to a HIGH state and the timer TIMER_1 (T0000) will Start counting up to 5 seconds.

The memory bit CUTOFF (W0.01) will change to a LOW state when the NC contact of Limit Switch LS_PISTON_STAMP (0.03) is in the HIGH state.

RUNG 3 (PISTON STAMP)

The Output PISTON_STAMP (100.01) will be ON when the NO contact of memory bit SYSTEM_ON (W0.00) and TIMER_1 (T0000) are in a HIGH state and the value in memory word WEIGHING_INDICATOR (D0) is equal to “15”.

The PISTON_STAMP (100.01) Output will be OFF if the NC contact of Limit Switch LS_PISTON_STAMP (0.03) is in the HIGH state.

PLC program for weighing system

RUNG 4 (ALARM)

When the NO contacts of memory bit SYSTEM_ON (W0.00) and TIMER_1 (T0000) are in a HIGH state and the value in memory word WEIGHING_INDICATOR (D0) is not equal to “15”, then the timer TIMER_2 (T0001) will Start counting up to 2 seconds.

When the timer TIMER_2 (T0001) has reached the “Set value”, the ALARM (100.02) Output will be ON.

RUNG 5 (COUNTER PRODUCT)

When the NO contact of memory bit SYSTEM_ON (W0.00) and the Limit Switch LS_PISTON_STAMP (0.03) are in the HIGH state, the value in memory word COUNTER_PRODUCT (D100) will increase (+1).

Weighing system for sticker machine PLC

RUNG 6 (RESET COUNTER)

When the STOP_SYSTEM (0.01) button is pressed, the value in the memory word COUNTER_PRODUCT (D100) will be reset to zero “0”.
