PLC Program with 2 Toggle Switches and 4 Motors

This article will teach you the PLC program with 2 toggle switches and 4 motors logic diagrams.

Last updated: March 22, 2024 7:38 am
Editorial Staff
PLC Tutorials
No Comments
Share
4 Min Read
SHARE

This article will teach you the PLC Program with 2 Toggle Switches and 4 Motors logic diagrams.

Contents
PLC Program with 2 Toggle SwitchesSchneider Electric PLC ExampleInput DetailsOutput Details2 Toggle Switches and 4 Motors LogicLogic Diagram ExplanationPLC Logic Result

Note: The logic diagram example is for students and engineering graduates to learn the PLC basics.

PLC Program with 2 Toggle Switches

Problem Statement

Design a PLC ladder logic for the following application.

We are using two toggle switches to control four motors.

If Switch 1 is ON, then Motor I and Motor II will be ON.

If Switch 1 is OFF, then Motor I will be OFF and Motor II will be ON.

If Switch 2 is ON, then Motor III and Motor IV will be ON.

If Switch 2 is OFF, then Motor III will be OFF and Motor I will be ON.

Schneider Electric PLC Example

Watch this PLC video to learn the programming example.

Simple PLC Example - Schneider Electric PLC Programming

Input Details

Digital Inputs:

This program’s required digital inputs are mentioned below.

Switch 1: I0.0

Switch 2: I0.1

Output Details

Digital Outputs:

This program’s required digital outputs are mentioned below.

Motor 1: Q0.0

Motor 2: Q0.1

Motor 3: Q0.2

Motor 4: Q0.3

2 Toggle Switches and 4 Motors Logic

PLC Program with 2 Toggle Switches and 4 Motors

Logic Diagram Explanation

We used EcoStruxure Machine Expert Basic PLC software for this example logic.

In the above program, we have used Normally Open Contact for Switch 1 (I0.0) and Switch 2 (I0.1).

We have used a Set Coil for Motor 2 (Q0.1), Motor 4 (Q0.3), and a normal Coil for Motor 1 (Q0.0), and Motor 3 (Q0.2).

For Motor 1 and Motor 2 to be ON, switch 1 should be ON

When Switch 1 is turned OFF, Motor 1 will turn OFF but Motor 2 will remain ON as we have used Set Coil for it.

Turning ON Switch 2 will turn ON Motor 3 and Motor 4.

Motor 3 will turn OFF when Switch 2 is turned OFF but Motor 4 for which the Set coil is used remains ON.

PLC Logic Result

Now we will see the PLC logic result with different input scenarios.

When Switch 1 is ON

program to switch on and off the motor

The signal flows through switch 1 as it is in true state, both Motor 1 and Motor 2 will turn ON.

When Switch 1 is OFF

Toggle Switch in PLC Ladder Logic

When switch 1 is turned OFF, Motor 1 will turn OFF and Motor 2 still remains ON as SET coil is used for Motor 2.

When Switch 2 is ON

How to Toggle a Bit in Ladder Logic

Motor 3 and Motor 4 will turn ON when switch 2 is turned ON. The input Switch 2 is used as Normally open Contact, in the true state, which will allow the signal to pass through it.

When Switch 2 is OFF

PLC Toggle Logic

After turning OFF switch 2, Motor 3 will turn OFF and Motor 4 will remain ON in which SET coil is used.

If you liked this article, please subscribe to our YouTube Channel for PLC and SCADA video tutorials.

You can also follow us on Facebook and Twitter to receive daily updates.
