Overhead Product Pressure Control Loop

Examine the overhead product pressure control loop (#33) in this distillation system (in the upper-right corner of the P&ID). Suppose PR-33 shows a pressure of 48.1 PSI, while PIC-33 shows a pressure of 50.0 PSI (equal to setpoint):

Pressure Control Loop

Overhead Product Pressure Control Loop

Identify which faults could account for the pressure indication discrepancy:

Distillation System P&ID

Distillation System P&ID

The below list shows some possibilities for the errors.

Identify which faults are possible and which are impossible to occur for this pressure control loop.

  • PR-33 calibration error
  • PT-33 calibration error
  • PIC-33 (input) calibration error
  • PY-33a calibration error
  • PY-33b calibration error
  • PV-33a calibration error
  • PV-33b calibration error

Answer:

  • PR-33 calibration error – Possible
  • PT-33 calibration error – Impossible
  • PIC-33 (input) calibration error – Possible
  • PY-33a calibration error – Possible
  • PY-33b calibration error – Impossible
  • PV-33a calibration error – Impossible
  • PV-33b calibration error – Impossible

Share your answers with us through below comments section.
