Magnetic Flow Meter Corrosion Effects

One important but small part of the Magnetic Flow Meter that gets affected by corrosion / Erosion rate is " The Electrodes ".

Last updated: November 2, 2023 11:41 am
Editorial Staff
Flow Measurement Instrumentation Design
2 Comments
Share
3 Min Read
SHARE

Corrosion / Erosion rate of a process fluid is provided in Piping material specifications (PMS)

Now the mag flow meter has Liner material.

Example:- PTFE

Magnetic Flow Meter

Magnetic Flow Meter Corrosion Effects

so where is corrosion coming into the picture?

Well there is one important but small part in mag flow meter that gets affected with corrosion / Erosion rate is :- “The Electrodes “

Because of the relatively small size of the electrode and the importance of the seal between the electrode and flow tube liner only small corrosion rates are acceptable, typically less than 0.002 inches per year.

Whenever possible, it is essential to select an electrode material with a corrosion rate of less than 0.002 inches per year

Reference:- Rosemount Technical Data Sheet TDS 3033

Magnetic Flow Meter Electrode Materials
Image courtesy: Rosemount

so if your pipe is of stainless steel due to corrosion issues we cannot blindly go with the same Stainless steel electrode. The corrosion rate must be checked !!

The piping compensates for this by increasing the thickness of the piping wall:- Corrosion allowance & pipe schedule thus come into the picture !!

A common Question:-

I did not check the corrosion rate while procuring the mag flow meter but still it worked?

This is so because usually, the Pipe material is carbon steel and we instrumentation dept. take SS316 as our choice on carbon steel pipe and since Stainless steel is far more corrosion resistant than Carbon steel we don’t check the corrosion rate.

But when pipe material is stainless steel or higher this becomes a significant consideration.

Especially if we are also selecting the same material as that of the pipe, we must verify the corrosion rate.

I have come across pipes with corrosion/erosion rates as high as 0.125 inches/year for Duplex 2205 pipes

Another instance where this Corrosion rate is critical to Instrumentation is while selecting diaphragm seal material

The Below article explains this concept in detail

Read this: Diaphragm Seal Material Selection

Thanks for Reading !!!

Hope it was useful !!

Author: Asad Shaikh

Profile: Linkedin

If you liked this article, then please subscribe to our YouTube Channel for Instrumentation, Electrical, PLC, and SCADA video tutorials.

You can also follow us on Facebook and Twitter to receive daily updates.

Read Next:

  • Instrument Tube Bending
  • Flow Meter Installation Guide
  • Temperature Sensor Accessories
  • How Weigh Feeder Works?
  • Valve Materials Comparison
Don't Miss Our Updates
Be the first to get exclusive content straight to your email.
We promise not to spam you. You can unsubscribe at any time.
Invalid email address
You've successfully subscribed !

Continue Reading

Configure the Instruments in Flow Control Loop
Heat Tracing Problems
Electrical Heat Tracing
Flow Transmitters Questions and Answers – Instruments Test
What is an Insertion Flow Meter? – Types, Principle, Advantages
Pneumatic Cylinder Air Flow Calculation
Share This Article
Facebook Whatsapp Whatsapp LinkedIn Copy Link
Share
2 Comments
  • harshal says:
    January 6, 2023 at 3:10 pm

    But how to check corrosion rate of fluid at laboratory scale before buying an instrument?

    Reply
  • Charles Palmer says:
    January 12, 2023 at 2:05 pm

    Platinum-alumina Cermet is used by Yokogawa in their Magflows. Totally corrosion free

    Reply
