Formula to Calculate 4-20ma from Percentage

Last updated: March 27, 2023 9:53 am
Editorial Staff
Formulas
1 Comment
Share
1 Min Read
SHARE

Calculate the equivalent 4-20 mA loop current value for any given percentage of signal. We need field transmitter span, lower range value and upper range value.

Contents
Calculate 4-20 mA from PercentageCurrent (mA) = [(16 ma)(X/100)] + 4Video Lesson

Calculate 4-20 mA from Percentage

Formula to Calculate 4-20ma from Percentage

Formula:

Current (mA) = [(16 ma)(X/100)] + 4

Where “X” is desired percentage of signal.

Video Lesson

How to Calculate 4 to 20 mA from Percentage? - Instrumentation Formula

Example:

calculate the ma for 40 % of signal

Current (mA) = (16 ma)(x/100)+4

Current (mA) = (16)(40/100)+4

Current (mA) = 10.4 ma
