Difference between Fixed Area & Variable Area FlowMeters

Study about the Difference between Fixed Area and Variable Area Flow Meters. Advantages and disadvantages of these flow meters.

Last updated: November 1, 2023 11:21 am
Editorial Staff
Flow Measurement
No Comments
Share
1 Min Read
SHARE

In this article, you will learn the difference between a fixed area flow meter and a variable flow meter.

Contents
Difference between Fixed Area and Variable Area Flow MetersWith orifice plates flow metersWith any type of variable area flow meter

Difference between Fixed Area and Variable Area Flow Meters

Difference between Fixed Area and Variable Area Flow Meters
Image Courtesy: spiraxsarco

With orifice plates flow meters

  • As the rate of flow increases, so does the differential pressure.
  • By measuring this pressure difference it is possible to calculate the flow rate through the flow meter.
  • The pass area (for example, the size of the hole in the orifice plate) remains constant.

With any type of variable area flow meter

  • The differential pressure remains almost constant as the flow rate varies.
  • The flow rate is determined by the position of the float.
  • The pass area (the area between the float and the tube) through which the flow passes increases with increasing flow.
comparison of Fixed Area & Variable Area Flow Meters

Source: spiraxsarco
