Differential Pressure Sensor with Pair of Strain Gauges

Last updated: June 6, 2020 12:31 pm
Editorial Staff
Practical Questions
No Comments
Share
1 Min Read
SHARE

The following differential pressure sensor uses a matched pair of strain gauges. As the differential pressure increases, one strain gauge becomes compressed while the other becomes stretched. A voltmeter registers the bridge circuit’s imbalance and displays it as a pressure measurement:

Contents
Differential Pressure SensorAnswer:Read Next:

Differential Pressure Sensor

Differential Pressure Sensor with pair of Strain Gauges

Determine the following:

  • Identify which port is the “high” pressure port
  • Identify what the voltmeter will register if fixed resistor R1 fails open
  • Identify a component fault that would drive the voltmeter full upscale (“peg” positive)
  • Identify another component fault that would drive the voltmeter full upscale (“peg” positive)

Answer:

Which port is the “high” pressure port: Port “B”

What will happen if fixed resistor R1 fails open: Voltmeter will drive fully upscale (“peg” positive)

Identify a component fault that would drive the voltmeter full upscale (“peg” positive):  as follows below

  • Strain gauge #1 fails shorted
  • Strain gauge #2 fails open
  • R1 fails open
  • R2 fails shorted

Share your answers with us through below comments section.

Read Next:

  • Vortex Flow Meter Sensors
  • Different Types of Load Cells
  • Types of Pressure Transducers
  • Piezo Resistive Strain Gauge
  • Industrial Instrumentation Questions

Credits: Tony Kuphaldt
