Communication between Wincc and Tia Portal

Last updated: March 4, 2021 12:15 pm
Editorial Staff
PLC Tutorials
No Comments
Share
3 Min Read
SHARE

This article is about communication between WinCC and TIA portal using simple programming examples and screenshots.

Wincc and Tia Portal

Siemens S7 300 CPU Status and LED Errors Explanation

Step 1:

Open TIA PORTAL. Create a new project. Configure the devices and open programming environment.

Step 2:

The same way, create a new project in HMI. I already created an article on it. Read the article before proceed here.

Step 3:

From the above two steps, we created new projects in Tia Portal and WinCC.

After creating new projects, let’s move to establish communication between them.

As shown in the below window click on option “HMI” and expand it. Double click on “device configuration”.

Communication between Wincc and Tia Portal

Step 4:

Click on “network view”. Here, you can see PLC is added to the network as we already have configured while creating a new project.

Make sure that you select CPU and HMI have which contains the same port for communication. Here, I have select HMI and CPU which have the same PROFINET port in common.

Network View in Tia Portal

Step 5:

Now as shown in the below window select Profinet port in green color and drag that to the same port of HMI. Doing that will create a network.

PLC and HMI Communicate

Step 6:

Now to check communication established properly select any one HMI or PLC and do right click on it to open the selection menu as shown in the below window.

Click on “compile” and select “hardware rebuild all”.

Compile Project in Tia Portal

Step 7:

You are done with communication. To check IP address select “HMI” as shown in the below window. Click on “device view”.

Tia Portal Device View

Step 8:

Following window will pop-up. Click on green color Profinet port. In the “general” section, select the “Profinet interface” where you can find an IP address and you can make changes with your application.

Tia Portal IP Protocol

Step 9:

Do follow the same procedure for CPU to check an IP address.

Author: Suhel Patel

If you liked this article, then please subscribe to our YouTube Channel for PLC and SCADA video tutorials.

You can also follow us on Facebook and Twitter to receive daily updates.
