RTD Calculator : Calculate Temperature from Resistance

Last updated: November 12, 2019 4:56 pm
Editorial Staff
Instrumentation Tools Temperature Measurement
9 Comments
Share
2 Min Read
SHARE

RTD Conversion tool: R to T

This is used to calculate temperature value of RTD sensor from known resistance.

This calculation tool used to find out the temperature value of a RTD sensor with known resistance.

Calculate Temperature from Resistance

Formula:

Resistive Temperature Detectors (RTDs) relate resistance to temperature by the following formula:

   RT = Rref[1 + α(T − Tref)]

Where,

RT = Resistance of RTD at given temperature T (ohms)
Rref = Resistance of RTD at the reference temperature Tref (ohms)
α = Temperature coefficient of resistance (ohms per ohm/degree)

Example:

The following example shows how to use this formula to calculate the resistance of a PT100 RTD with a temperature coefficient value of 0.00392 at a temperature of 35 degrees Celsius:

Assuming Temperature Reference = 0 Degrees

For PT100 RTD the Rref = 100

RT = 100 Ω[1 + (0.00392)(35 − 0)]

RT = 100 Ω[1 + 0.1372]

RT = 100 Ω[1.1372]

RT = 113.72 Ω

For Temperature to Resistance conversion also the same above formula applies.

The above given is a basic equation only for RTD calculation.

Note:

1.The above RTD calculation tool designed for a standard PT100 sensor.

2.If you are interested to calculate for a different RTD then change the fixed constant values as per the sensor type.
