Circular Chart Recorder Calibration Procedure

Last updated: September 28, 2022 2:43 pm
R Jagan Mohan Rao
Common Guest Articles
3 Comments
Share
2 Min Read
SHARE

Barton Make Circular Chart Recorder. Can you help me out with the calibration procedures ?

Contents
Circular Chart RecorderCalibration Procedure:

Circular Chart Recorder

Two types of Circular Chart recorders are available for pressure recording.

One type is applying direct process pressure. For Example 0-100 psi range.

Recorder need to be calibrated according to the operating range on dead weight tester, This is same like calibration of pressure gauge in Lab.

Another type works on output from 3-15 PSI signal from Pressure Transmitter.

Calibrate recorder at 3 psi as zero and 15 psi at full scale.

Calibration Procedure:

Step 1: Apply known range pressure by a dead weight tester or 3-15 psi by precision regulator.

Step 2: Apply full range pressure to recorder. Adjust linkage to recorder so that pointer is max reading on the chart scale.

Step 3: Reduce pressure to zero and check the pointer reads zero on the chart.Adjust pointer if necessary.

Step 4: Repeat the steps 2 and 3 until both readings are correct.

Step 5 : Recorder linearity adjustment by keeping the signal 50 % of max reading on the chart. Adjust 50%.

Step 6 : Check the reading for 0%, 50% and full scale. you may need to adjust many times till the recorder readings are correct.

Step 7 : Record all readings on Calibration sheet.

Don't Miss Our Updates
Be the first to get exclusive content straight to your email.
We promise not to spam you. You can unsubscribe at any time.
Invalid email address
You've successfully subscribed !

Continue Reading

What is Fuzzy Logic? Advantages, Disadvantages, Applications
Modern Instrumentation & IoT: Key Innovations & Trends
Hydraulic and Pneumatic P&ID Diagrams and Schematics
What is a Process Alarm? Types of Alarms
What is Eddy Current and Eddy Current Loss?
Capacity Control of Absorption Chillers
Share This Article
Facebook Whatsapp Whatsapp LinkedIn Copy Link
Share
3 Comments
  • Rajesh Das says:
    December 23, 2018 at 6:57 pm

    Thank you so very much for uploading the article on chart recorder calibration procedure. It would be great tool in carrying out the field assignments.

    Reply
  • Vijay Methe says:
    April 26, 2023 at 12:47 pm

    Is it necessary to record time reading or Time calibration of Circular Chart recorder is essential?

    Reply
  • Hans Koning-Bastiaan says:
    October 10, 2024 at 11:04 pm

    I have a foxboro Square root extractor, but not the calibration procedure.
    Do you have the calibration procedure and if so can I have a copy?
    I use them for educational purpose.
    Hans

    Reply
