Download a Ladder logic program to GE PLC

How-to Download a Ladder logic program to GE PLC Programming, GE PLC program upload, GE PLC program download, GE PLC Logic Save.

Last updated: November 2, 2023 2:04 pm
Editorial Staff
PLC Tutorials
1 Comment
Share
3 Min Read
SHARE

How-to Download a Ladder logic program to GE PLC Programming, GE PLC program upload, GE PLC program download, GE PLC Logic Save.

Download a Ladder logic program to GE PLC

Procedure to program and download with GE Proficy machine Edition-Proficy Machine Edition

1)Click on File>New

2)Select Empty Project .

A window will pop up.Enter the project name.

Then Click ok

2)On right pane you can see navigator window. Select the projected you created.

Right Click on it.

Select the CPU type by clicking on “Add Target”

Download a Ladder logic program to GE PLC
Download a Ladder logic program to GE PLC

3.Click on Hardware Configuration.

First 3 slots are already configured with default configuration

Click on slot 4.

A new window will pop up.Select communications tab.

Select interface module and click ok.

Enter the details.

  • IP Address
  • Subnet Mask
  • Status Address
  • Enable redundant IP
Ladder logic program to GE PLC
Ladder logic program to GE PLC



GE PLC Ladder logic
Ladder logic program to GE PLC

4.Select each slot and configure as per requirement.

Select the IO modules as per project requirement.

5.Now click on Logic .There you can see Program Block . Select “Main”and Click on it

You can develop ladder logic program on right pane. Ladder logic symbols are available on top menu.



GE Proficy machine Edition
GE Proficy machine Edition

6.To add a parallel rung you need to use “Cntrl + Z”

GE Proficy PLC Download
GE Proficy machine Edition PLC Download

7.Now click on target menu and Click on validate

You can see following message if it is ready to be downloaded

“Validating Complete – 0 error(s), 0 Warning(s)

8.Click on Online/Offline button and it will connect the PLC to engineering PC.

(In properties TAB enter the IP address )



Online or Offline GE PLC
Online/Offline button GE PLC

9.Click on stop button and Disable the output.

10.Click on download button

download GE PLC
download button GE PLC
