Home / Online Test / Power Electronics Questions and Answers – SOAs Online Test Power Electronics Questions and Answers – SOAs S Bharadwaj ReddyLeave a comment Power Electronics Questions and Answers – SOAs Power Electronics Objective Questions & Answers 0% As the FSOA increases, the pulse width remains constant decreases increases vanishes Correct! Wrong! - Continue >> For a transistor, the safe operating area (SOA) is a plot of Ib versus Vce Ic versus time Ib versus Ic Ic versus Vce Correct! Wrong! - Continue >> A device is operating at Ic = 4A & Vce = 50V. For the device to operate at Ic = 20A (Without damaging), current has to increased further voltage should be increased voltage can be kept constant voltage should be reduced Correct! Wrong! - Continue >> The forward safe operating area (FSOA) pertains to the operation when the device is fired at a 50% Duty cycle the device is operated on DC the device is operated on AC The device is forward-biased Correct! Wrong! - Continue >> The SOAs are plotted always on a _________ scale logarithmic frequency time polynomial Correct! Wrong! - Continue >> For a BJT, find the maximum power dissipation when the device is safely operated at Vce = 90V and Ic = 0.5A 30 Watts 40 Watts 35 Watts 45 Watts Correct! Wrong! - Continue >> The SOAs provided by the manufacturers are for a particular duty cycle operation all the conditions multi pulse operation & all the temperature single pulse operation & a particular temperature Correct! Wrong! - Continue >> The SOA for an IGBT is plotted for Ic versus Vce Ig versus Vce Ic versus Vge Ig versus Ic Correct! Wrong! - Continue >> For MOSFET’s SOA, as the pulse width goes on increasing, the maximum voltage rating ____ & current rating ____ is constant, increases increases, decreases constant, decreases decreases, is constant Correct! Wrong! - Continue >> The SOA for a MOSFET is plotted for Id versus Vgs Id versus Vds Ig versus Id Ig versus Vds Correct! Wrong! - Continue >> Share the quiz to show your results ! Facebook Facebook Just tell us who you are to view your results ! Show my results >> SOAs I got %%score%% of %%total%% right Share your results Facebook Facebook Twitter Google+ ↺ PLAY AGAIN ! Previous Post:IGBT Objective Questions – Part 2Next Post:Thyristors Questions and Answers – Part 1 Related Articles Online Test Analog Recorders Objective Questions March 12, 2017 Online Test Power Factor Correction by Synchronous Motors January 2, 2015 Online Test Analog Electronics Objective Questions – Set 2 May 18, 2017 Online Test Measurement and Calibration Objective Questions January 1, 2017 Online Test Register-Transistor Logic (RTL) Objective Questions May 1, 2015 Online Test Digital Electronics Objective Questions – Set 6 May 18, 2017 Online Test Microprocessors Objective Questions – Set 3 May 17, 2017 Online Test 3-Phase Bridge Inverters Objective Questions – 3 December 1, 2014 Online Test Torque in DC Machines January 2, 2015 Online Test Electrical Machines Objective Questions – Set 31 December 2, 2014 Online Test GTO Questions and Answers December 1, 2014 Online Test Measurement of Xd and Xq January 2, 2015 Also Read : Fluidic Systems Objective Questions January 17, 2017 Power Systems Objective Questions & Answers – Set 14 January 3, 2015 PWM Inverters Objective Questions – 3 December 1, 2014 Leave a Reply Cancel reply Your email address will not be published. Required fields are marked *Comment Name * Email * Website Save my name, email, and website in this browser for the next time I comment.
