Thyristors Questions and Answers – Part 4

A tangent drawn from the Y-axis to the Pavg on the gate characteristics gives the value of the

Latching current for an SCR is 100 mA, a dc source of 200 V is also connected to the SCR which is supplying an R-L load. Compute the minimum width of the gate pulse required to turn on the device. Take L = 0.2 H & R = 20 ohm both in series.

Higher the magnitude of the gate pulse

The average gate power dissipation for an SCR is 0.5 Watts the voltage applied to the gate is Vg = 10 V. What is the maximum value of current Ig for safe operation?

The gate-source voltage is Es = 16 V and the load line has a slope of 128 V/A. Calculate the gate current for an average gate power dissipation of 0.5 W.

Latching current for an SCR is 100 mA, DC source of 200 V is also connected from the SCR to the L load. Compute the minimum width of the gate pulse required to turn on the device. Take L = 0.2 H.

From the two transistor (T1 & T2) analogy of SCR, the total anode current of SCR is ___________ in the equivalent circuit.

For an SCR, the gate-cathode characteristic has a slop of 130. The gate power dissipation is 0.5 watts. Find Ig

The two transistor model of the SCR can obtained by

Consider the two transistor analogy of SCR, if α₁ & if α₂ are the common-base current gains of both the transistors then to turn-on the device
