Identify Valve Parts Quiz with Answers

Identify Valve parts by clicking on the question mark that represents each component, such as the Yoke, Bonnet, or Stem, etc.

Last updated: August 23, 2024 9:17 pm
Editorial Staff
Control Valves Instrumentation MCQ
No Comments
Share
5 Min Read
SHARE

Identify Valve parts by clicking on the question mark that represents each component, such as the Yoke, Bonnet, Stem, etc.

Contents
Identify Valve PartsWhat is the primary role of packing in a gate valve?The stuffing box in a gate valve is used to house which component?What is the purpose of the flange in a gate valve?What is the function of the yoke in a gate valve?The main function of the body in a gate valve is to?What is the function of the handwheel in a gate valve?What is the role of the stem in a gate valve?What do seat rings in a gate valve ensure?The gasket in a gate valve serves what primary function?The gate (disc) in a gate valve is used to?The grease fitting in a gate valve is primarily used to?The bonnet in a gate valve is primarily used for what purpose?The packing gland in a gate valve is designed to?In a gate valve, the nut primarily functions to?

Your task is to correctly match each part to its location on the valve diagram. These questions are based on an interactive image quiz where participants need to identify and click on different parts of a gate valve based on the provided labels.

Identify Valve Parts

Let’s start the quiz by clicking on the below start button.

Start Valve Parts Quiz

The animation below shows the demo of the valve quiz.

Identify Valve Parts Quiz with Answers

Question 1

What is the primary role of packing in a gate valve?

A. Secure the handwheel

B. Prevent stem leakage

C. Align the gate

D. Guide fluid flow

Show the Answer

Prevent stem leakage

Question 2

The stuffing box in a gate valve is used to house which component?

A. Gate

B. Yoke

C. Packing

D. Bonnet

Show the Answer

Packing

Question 3

What is the purpose of the flange in a gate valve?

A. Seal the bonnet

B. Connect the valve to pipes

C. Direct fluid flow

D. Guide the stem

Show the Answer

Connect the valve to pipes

Question 4

What is the function of the yoke in a gate valve?

A. Guides the disc

B. Connects stem to handwheel

C. Secures the valve body

D. Prevents leakage

Show the Answer

Connects stem to handwheel

Question 5

The main function of the body in a gate valve is to?

A. Support external components

B. Support internal components

C. Adjust fluid pressure inside the valve

D. Seal the valve

Show the Answer

Support internal components

Try Drag and Drop Valve Quiz:

Interactive Control Valve Parts Quiz: Drag & Drop Challenge

Question 6

What is the function of the handwheel in a gate valve?

A. Secure the yoke

B. Regulate fluid flow

C. Align the stem

D. Rotate the stem

Show the Answer

Rotate the stem

Question 7

What is the role of the stem in a gate valve?

A. Seals the bonnet

B. Moves the gate up and down

C. Holds the valve body

D. Connects to the handwheel

Show the Answer

Moves the gate up and down

Question 8

What do seat rings in a gate valve ensure?

A. Secure the bonnet

B. Hold the disc in place

C. Guide the stem’s movement

D. Prevent leakage when the gate is closed

Show the Answer

Prevent leakage when the gate is closed

Question 9

The gasket in a gate valve serves what primary function?

A. Lubricates the stem

B. Aligns the gate

C. Guides fluid flow

D. Prevents leakage at joints

Show the Answer

Prevents leakage at joints

Question 10

The gate (disc) in a gate valve is used to?

A. Regulate fluid temperature

B. Connect to the yoke

C. Control fluid flow

D. Seal the bonnet

Show the Answer

Control fluid flow

Question 11

The grease fitting in a gate valve is primarily used to?

A. Seal the bonnet

B. Lubricate the stem

C. Adjust the handwheel

D. Secure the gate

Show the Answer

Lubricate the stem

Question 12

The bonnet in a gate valve is primarily used for what purpose?

A. Secures the valve disc

B. Guides the stem

C. Regulates flow

D. Seals the valve body

Show the Answer

Seals the valve body

Question 13

The packing gland in a gate valve is designed to?

A. Tighten the stuffing box

B. Lubricate the valve

C. Guide the stem

D. Secure the bonnet

Show the Answer

Tighten the stuffing box

Question 14

In a gate valve, the nut primarily functions to?

A. Rotate the handwheel

B. Secure the bonnet

C. Fasten components

D. Adjust the gate

Show the Answer

Fasten components
