Transmitter Calibration Range of a Vessel Level

Determine the calibration range of a transmitter in order to measure the vessel level into an output signal of 4 to 20 mA.

Last updated: November 12, 2020 9:39 am
Editorial Staff
Practical Questions
No Comments
Share
1 Min Read
SHARE

The following storage vessel holds liquid heptane, a hydrocarbon with an approximate specific gravity of 0.68.

A pressure transmitter located at the bottom infers heptane level by hydrostatic pressure (head).

Determine the calibration range of this pressure transmitter in order to properly translate the range of vessel level (0 to 14 feet) into an output signal of 4 to 20 mA.

Transmitter Calibration Range

Transmitter Calibration Range of a Vessel Level Please express the transmitter’s calibration range in units of inches W.C. (inches of water column).

Then, determine the following (assuming the transmitter has been properly calibrated for the application):

Transmitter output signal (mA) at 8 feet of level

Heptane level at 5.7 mA signal output

Answer

Lower range-values (LRV): 0 inches W.C. input = 4 mA output

Upper range-values (URV): 114.24 inches W.C. input = 20 mA output

Transmitter output signal (mA) at 8 feet of level = 13.14 mA

Heptane level at 5.7 mA signal output = 1.4875 feet

Share your answers & explanation with us through the below comments section.

Read Next:

  • Impulse Tubing Leak
  • Control Valve Noise
  • Density and Specific Gravity
  • Pressure Sensing Level Sensor
  • LRV URV of DP Level Transmitter

Credits: Tony R. Kuphaldt
