Circuit Control Devices Multiple Choice Questions & Answers

In this article, you will find the circuit control devices objective questions and answers for instrumentation, electrical, and electronics engineers.

Circuit Control Devices Multiple Choice Questions

Circuit Control Devices Multiple Choice Questions

The below list provides all the multiple-choice questions (MCQ) related to the circuit control devices.

Answers are available at the bottom of the article.

1. What is the maximum number of different single-pole, double-throw switch positions possible?

A)Two
B)Four
C)Three
D)One

2. When you perform preventive maintenance on a switch, which of the following items should be checked?

A)The terminals for corrosion
B)The switch operation for smooth and correct operation
C)All of these answers
D)The physical condition of the switch

3. Control of a circuit requiring a temporary actuation signal is provided by which of the following switches?

A)Rotary
B)Momentary
C)Locked-out
D)Locked-in

4. To guard against the accidental actuation of a circuit, which of the following types of switches are used?

A)Momentary
B)Rotary
C)Locked-out
D)Locked-in

5. What should be used to clean the contacts of a relay?

A)A jeweler’s file
B)Emery cloth
C)A burnishing tool
D)Sandpaper

6. Checking a switch with the circuit power NOT applied is accomplished by using which of the following meters?

A)Frequency meter
B)Wattmeter
C)Ohmmeter
D)Temperature meter

7. What should be used to adjust contact clearances on a relay?

A)A pair of hemostats
B)A pair of pliers
C)A point bender
D)A burnishing tool

8. Control or selection of one or more circuits is a function of which of the following switches?

A)A multi-contact switch
B)A manual switch
C)A single contact switch
D)An automatic switch

9. A switch actuator is described by which of the following terms?

A)Four-position
B)Toggle
C)Momentary
D)Two-position

10. Which of the following is an automatic switch?

A)A dial or push button on a telephone
B)An ignition switch on a motor vehicle
C)A switch that turns on a light in a refrigerator
D)A channel selector on a television

11. Checking a switch with the power applied is accomplished by using which of the following meters?

A)Megger
B)Wattmeter
C)Voltmeter
D)Ohmmeter

12. Designation of switch voltage rating is based on which of the following voltage values?

A)Maximum
B)Nominal
C)Minimum
D)Average

13. If a relay is hermetically sealed with an opaque cover, which of the following methods should be used to determine whether the relay is operating?

A)Shake the relay and listen for loose parts
B)Place your finger on the cover and feel the relay contact movement
C)Remove the cover and visually observe the relay contacts when the relay is activated
D)Activate the relay and observe whether a metal object is attracted by the magnetic field

14. What is the common name for an accurate snap-acting switch?

A)Multi-switch
B)Maxi-switch
C)Mini-switch
D)Micro-switch

15. Designation of switch current rating is based on which of the following current values?

A)Nominal
B)Minimum
C)Average
D)Maximum

16. What is the maximum number of different single-pole, single-throw switch positions possible?

A)Two
B)Three
C)Four
D)One

17. Circuit control devices should NOT be used for which of the following reasons?

A)To apply power to a device when work is completed on it
B)To select the function or circuit desired within a device
C)To remove power from a malfunctioning device
D)To adjust the power level of a device

18. To guard against the accidental turning off of a circuit, which of the following types of switches are used?

A)Momentary
B)Rotary
C)Locked-out
D)Locked-in

19. If a solenoid is not operating properly, which of the following items need NOT be checked?

A)Energizing voltage
B)Coil
C)Armature
D)Plunger

20. A solenoid is commonly used in which of the following devices?

A)A fuel quantity indicating system
B)A starter for a motor vehicle
C)A sound-powered telephone system
D)A shipboard lighting system

21. A solenoid is based upon which of the following principles?

A)A soft iron core moving in a magnetic field creates a current
B)A thermocouple produces a current when heated
C)A coil attracts a soft iron core when current flows in the coil
D)A bimetallic strip bends when it is heated

22. Which of the following are types of circuit control devices?

A)Solenoids
B)Relays
C)All of these answers
D)Switches

23. If a relay is NOT operating properly, which of the following items need NOT be checked?

A)The armature resistance
B)The contact spacing
C)The terminal leads
D)The contact surfaces

24. Which of the following is a manual switch?

A)A distributor
B)A thermostat
C)A light switch
D)A limit switch

Click Here for Answers
